成功案例
山西省平定縣農村宅基地使用權限調查及數據入庫工作地圖制作項目
發布時間：
2025-04-11 10:18
瀏覽次數：
239
區域網1加密平差精度如下：
Parameter | X/Omega | Y/Phi | Z/Kappa | XY |
RMS Control | 0.034 | 0.039 | 0.029 | 0.037 |
RMS Check | 0.034 | 0.063 | 0.083 | 0.050 |
RMS Limits | 1.000 | 1.000 | 1.000 | |
Max Ground Residual | 0.076 | 0.065 | 0.060 | |
Residual Limits | 1.000 | 1.000 | 1.000 | |
Mean Std Dev Object | 0.020 | 0.022 | 0.042 | |
RMS Photo Position | ||||
RMS Photo Attitude | ||||
Mean Std Dev Photo Position | 0.037 | 0.037 | 0.032 | |
Mean Std Dev Photo Attitude | 0.007 | 0.007 | 0.003 | |
Sigma | 2.0 um | |||
Control Points Used | 13 | |||
Check Points Used | 3 | |||
區域網2加密平差精度如下：
Parameter | X/Omega | Y/Phi | Z/Kappa | XY |
RMS Control | 0.028 | 0.030 | 0.017 | 0.029 |
RMS Check | 0.015 | 0.016 | 0.027 | 0.016 |
RMS Limits | 1.000 | 1.000 | 1.000 | |
Max Ground Residual | 0.068 | 0.069 | 0.044 | |
Residual Limits | 1.000 | 1.000 | 1.000 | |
Mean Std Dev Object | 0.020 | 0.019 | 0.039 | |
RMS Photo Position | ||||
RMS Photo Attitude | ||||
Mean Std Dev Photo Position | 0.033 | 0.035 | 0.028 | |
Mean Std Dev Photo Attitude | 0.006 | 0.006 | 0.002 | |
Sigma | 1.9 um | |||
Control Points Used | 18 | |||
Check Points Used | 3 | |||
